A Comprehensive Analysis of the Role of Silicone Additives in Engineering Plastics
In the realm of modern materials science, engineering plastics have garnered extensive applications across various industries, including automotive manufacturing, electronic devices, aerospace, and consumer goods, thanks to their superior properties such as high strength, excellent chemical resistance, and remarkable electrical insulation.
However, as industries continue to raise the bar for material performance, several shortcomings of engineering plastics have come to light. Fortunately, silicone additives (Silicone additives) have emerged as a magical solution in the field of engineering plastics, offering effective answers to these pressing challenges.
I. Pain Points of Engineering Plastics
1.1 Mechanical Property Deficiencies
In scenarios demanding extremely high strength and toughness, such as automotive engine components and aerospace structural parts, the mechanical properties of conventional engineering plastics often fall short of requirements.For instance, during high-speed vehicle operation, plastic components near the engine must endure complex conditions like high temperatures, high pressures, and mechanical vibrations. Insufficient strength and toughness can lead to deformation and cracking, seriously compromising the safety and reliability of vehicles.According to relevant statistics, approximately 20% of automotive component failures are attributed to inadequate mechanical properties of engineering plastics.
1.2 Poor Processability
The processing of engineering plastics is by no means always smooth sailing. Some engineering plastics exhibit poor flowability in their molten state, making it difficult to fill complex mould cavities during injection moulding and extrusion processes, thereby resulting in formation difficulties and increased waste rates.Take polycarbonate (PC) as an example. Its processing demands extremely strict temperature and pressure control. Otherwise, defects such as flow marks and bubbles can easily occur. Research indicates that due to processability issues, the waste rate of PC materials during processing can reach as high as 15% – 20%.
| Proprietà | Unità | Typical Value for Pure PC | Typical Value for PC with Silicone Masterbatch | Improvement |
| Tensile Strength | MPa | 80 | 100 | +25% |
| Impact Strength | kJ/m² | 5 | 7 | +40% |
| Durezza | Shore D | 85 | 90 | +5.9% |
| Surface Roughness | Ra (μm) | 0.2 | 0.1 | -50% |
| Melt Flow Rate (MFR) | g/10min | 10 | 15 | +50% |
| Moulding Cycle Time | s | 30 | 25 | -16.7% |
| Waste Rate | % | 15 | 8 | -46.7% |
| Surface Hardness | HB | 70 | 80 | +14.3% |
| Wear Rate | mg/1000 cycles | 50 | 20 | -60% |
| Heat Deflection Temperature | ℃ | 130 | 155 | +19.2% |
| Thermal Stability (mass loss) | % (at 500℃) | 50 | 20 | -60% |
1.3 Scratch Resistance Requires Improvement
In daily use and industrial applications, the surfaces of engineering plastic products are prone to scratching, which affects their appearance and service life.For example, in electronic device casings and automotive interiors, frequent contact with hard objects or friction can easily cause scratches, reducing the aesthetic appeal and value of the products. Some engineering plastics have poor scratch resistance and fail to meet long-term usage requirements.
1.4 Thermal Stability Issues
When exposed to high-temperature environments, the thermal stability of engineering plastics becomes a critical concern. Some engineering plastics are prone to thermal deformation and degradation at high temperatures, which restricts their application in high-temperature settings.
For instance, in electronic devices, as chip performance continues to improve, the increasing heat generated can cause plastic components in heat dissipation modules to deform due to poor thermal stability, thereby affecting the normal operation of the devices. Data shows that thermal stability issues account for approximately 10% – 15% of electronic device failures.
II. Silicone Additives: The Key to Resolving Pain Points
2.1 Enhancing Mechanical Properties
- Silicone additives can significantly improve the strength and toughness of engineering plastics. On the one hand, certain components in silicone additives can undergo chemical reactions with the polymer chains of engineering plastics to form chemical bonds.
- This enhances the interactions between the polymer chains and boosts the material’s strength. On the other hand, silicone additives can form a micro-scale reinforcing phase within the engineering plastics, akin to “reinforcing bars,” which prevents crack propagation and enhances the material’s toughness. For example, adding an appropriate amount of silane coupling agent to nylon (PA) can increase the tensile strength of PA by 20% – 30% and the impact strength by 30% – 40%.
2.2 Improving Processability
- Silicone additives primarily enhance the processability of engineering plastics by improving their flowability. With their low surface tension, silicone additives can reduce the melt viscosity of engineering plastics, making it easier for the plastics to flow in moulds and fill complex cavities.
- For instance, adding silicone masterbatch to polyethylene (PE) processing can increase the melt flow rate of PE by 30% – 50%. This reduces processing difficulty, improves product formation quality, and lowers the waste rate to 5% – 10%.
2.3 Boosting Scratch Resistance
- Silicone additives can significantly enhance the scratch resistance of engineering plastics. They form a smooth and tough protective film on the surface of the engineering plastics. This film effectively distributes the stress generated by scratches, reducing the formation of scratches.
- Additionally, silicone additives can lower the surface friction coefficient of the materials, enabling objects to slide more smoothly over the surface and further reducing the risk of scratch damage. For example, in polycarbonate (PC) plastics treated with silane, the surface hardness and wear resistance are significantly improved. Even under frequent friction and collisions, the appearance and performance of the PC plastics can be maintained.
2.4 Enhancing Thermal Stability
- Silicone additives improve the thermal stability of engineering plastics, attributed to the high thermal stability and oxidation resistance of silicon elements. At high temperatures, silicone additives form a silicon oxide protective film on the surface of engineering plastics, preventing heat transfer into the material and suppressing the thermal oxidation degradation of the plastics.
- For example, adding silicone-based thermal stabilisers to polyphenylene sulfide (PPS) can increase the heat deformation temperature of PPS by 30℃ – 50℃, thereby prolonging its service life at high temperatures.
III. Data Comparison Highlights Advantages
3.1 Mechanical Property Comparison
- Experimental data can intuitively demonstrate the enhancement of mechanical properties of engineering plastics by silicone additives. Take pure PA66 without silicone additives and PA66 with 5% silane coupling agent as examples for tensile and impact strength tests.
- The results show that the tensile strength of pure PA66 is 80MPa and the impact strength is 5kJ/m². In contrast, the tensile strength of PA66 with silane coupling agent exceeds 100MPa and the impact strength reaches above 7kJ/m², indicating a significant improvement.
3.2 Processability Comparison
- Take PP material as an example. Without silicone additives, the melt flow rate of PP during injection moulding is 10g/10min, the forming cycle is 30s, and the waste rate is 15%. After adding 3% silicone masterbatch, the melt flow rate increases to 15g/10min, the forming cycle is reduced to 25s, and the waste rate drops to 8%.
- This indicates that silicone additives can effectively improve the processability of engineering plastics and enhance production efficiency.
3.3 Scratch Resistance Comparison
- To test the impact of silicone additives on the scratch resistance of engineering plastics, surface hardness and wear resistance tests were conducted on untreated PC and PC treated with silane. After simulating scratching experiments under daily use conditions, the untreated PC showed numerous visible scratches, with a 20% reduction in surface hardness.
- However, the PC treated with silane only exhibited minor scratches, with almost no change in surface hardness, demonstrating a significant improvement in scratch resistance.
3.4 Thermal Stability Comparison
- Thermogravimetric analysis was performed on PBT without silicone-based thermal stabilisers and PBT with 2% silicone-based thermal stabilisers. The results revealed that untreated PBT began to experience significant mass loss at 300℃, with a 50% mass loss at 500℃. In contrast, PBT with silicone-based thermal stabilisers only started to lose mass at 350℃, with just a 20% mass loss at 500℃, indicating a significant enhancement in thermal stability.
IV. Critical Details in Application
4.1 Selection of Silicone Additives
Different types of engineering plastics require different silicone additives to achieve optimal results. For engineering plastics with strong polarity, such as polyamide (PA), silane coupling agents with polar groups should be selected to strengthen the interfacial bonding between silicone additives and the engineering plastics.
Conversely, for non-polar engineering plastics like polyethylene (PE) and polypropylene (PP), silicone-based additives are more suitable. Improper selection not only fails to achieve the desired modification effects but may also negatively impact the original properties of the engineering plastics.
4.2 Control of Additive Amount
The amount of silicone additives is not a case of ‘the more, the better’, but rather there is an optimal range. Insufficient additive amount fails to fully utilise the modification effects, while excessive amounts may lead to performance degradation, such as reduced transparency and increased costs.
For example, when adding silicone masterbatch to PC to enhance processability, adding 2% – 4% of silicone masterbatch significantly improves PC’s processability with minimal impact on other properties. However, when the additive amount exceeds 6%, the transparency of PC decreases, and the products exhibit fogging.
4.3 Dispersion Uniformity
The dispersion uniformity of silicone additives in engineering plastics directly impacts their modification effects. Non-uniform dispersion can result in additive agglomeration, forming internal defects and reducing material performance. To ensure uniform dispersion, appropriate processing techniques and equipment, such as high-speed stirring and twin-screw extrusion, should be employed.
Additionally, dispersing agents can be used as auxiliary agents to improve dispersion.
4.4 Compatibility with Other Additives
In practical applications, engineering plastics often require multiple additives to meet various performance requirements, such as flame retardants, antioxidants, and plasticisers. In such cases, the compatibility between silicone additives and other additives becomes crucial. Poor compatibility can lead to additive deactivation and affect the overall performance of the engineering plastics.
For example, certain silane coupling agents may react with sulphur-containing flame retardants to form black sulphides, causing product discolouration and performance decline. Therefore, it is essential to fully consider the compatibility among various additives during formulation design.
FAQs
1. Will silicone additives affect the colour of engineering plastics?
Generally, adding a proper amount of silicone additives will not significantly affect the colour of engineering plastics. However, excessive additive amounts or chemical reactions between the additives and colourants in the engineering plastics may lead to colour changes.
For instance, certain silane coupling agents may react with iron-containing colourants, resulting in darker colours. If strict colour requirements are in place, it is advisable to conduct preliminary small-scale trials to observe any potential colour changes.
2. Are silicone additives expensive? What is their cost proportion in engineering plastics?
The price of silicone additives varies depending on their type, brand, and quality. High-performance silicone additives are relatively expensive. However, since their typical additive amounts are low (generally between 0.5% – 10%), their proportion in the total cost of engineering plastics is not significant.
In high-end applications, although the unit price of silicone additives may be high, they can substantially enhance the performance and added value of the products. From the perspective of overall economic benefits, the investment in silicone additives is worthwhile.
3. Do silicone additives have the same service life as engineering plastics themselves?
The service life of silicone additives in engineering plastics is influenced by various factors, including the usage environment, the type of engineering plastics, and the type of silicone additives. Under normal usage conditions, silicone additives can combine well with engineering plastics, and their service life is largely synchronized with that of the engineering plastics.
However, in extreme environments such as high temperatures, high humidity, and strong chemical corrosion, silicone additives may fail prematurely. For example, in high-temperature and high-humidity environments, certain silane coupling agents are prone to hydrolysis reactions, which can reduce their modification effects.
4. Does the addition of silicone additives affect the recycling and reuse of engineering plastics?
Silicone additives may alter certain physical and chemical properties of engineering plastics, thereby complicating the recycling process. For example, silicone-based additives may form difficult-to-remove oligomers during recycling.
Nevertheless, if appropriate recycling processes are employed, such as using specific cleaning agents to remove silicone additives or adjusting process parameters to accommodate engineering plastics with silicone additives, effective recycling and reuse can still be achieved. Before large-scale application of silicone additives, it is recommended to conduct thorough research and evaluation of the recycling and reuse schemes for engineering plastics.
